SC55037
Product Name:Caliper Guides & Seals Repair Kit
Product Size/Weight:1,655 gr
| Order | Image | Code | Name | Size |
| 1 |
|
SC55501 | Guide Pin Ø37 x 123 mm | 0,670 gr |
| 2 |
|
SC55504 | Guide Pin Ø36,80 x 70 mm | 0,365 gr |
| 3 |
|
SC55589 | Bolt M16 x 1,5 x 103 mm | 0,190 gr |
| 4 |
|
SC55588 | Bolt M16 x 1,5 x 73 mm | 0,140 gr |
| 5 |
|
SC55605 | Inner Boot | 0,020 gr |
| 6 |
|
SC55506 | Plastic Washer | 0,002 gr |
| 7 |
|
SC55507 | Bronze Bush Ø41 x Ø37 x 73 mm | 0,145 gr |
| 8 |
|
SC55575 | Bronze Bush Ø41 x Ø37 x 34 mm | 0,063 gr |
| 9 |
|
SC55510 | Plastic Cap | 0,010 gr |
| 10 |
|
SC55545 | O-ring | 0,001 gr |
| 11 |
|
SC55566 | Plug | 0,010 gr |
| 12 |
|
SC55518 | Pin Circlip Ø43 x 1,5 mm | 0,005 gr |
Note: Some sets may contain several of the related parts.
| Ad | Değer |
| B.V. | 09.801.08.69.0 |
